| Κωδικός ανταλλακτικού | Άλλος κωδικός | Αντικατάσταση κωδικού |
|---|---|---|
| 43012750 | Timer/select. knob | |
| 41013044 | Therm/potent. knob spring | |
| 41043691 | Control panel with Sensor | |
| 41043974 | Dispenser drawer front | |
| 41043621 | Light Guide - Digital Display | |
| 41019256 | R/H side frame | |
| 43021070 | R/H side frame | |
| 41019257 | L/H side frame | |
| 43021069 | L/H side frame | |
| 41021927 | Top rear frame | |
| 91617795 | Trade mark plate | |
| 41022956 | Work top | |
| 41018447 | Hinge | |
| 43010993 | Hinge | |
| 41030970 | Porthole outer frame | |
| 43011750 | Porthole outer frame | |
| 41040031 | Porthole glass | |
| 49007928 | Door catch with spring service pack | |
| 41032503 | Porthole door complete | |
| 43015358 | Porthole door complete | |
| 41030969 | Porthole door inner frame | |
| 43012569 | Porthole door inner frame | |
| 41024833 | Rear panel | |
| 43024291 | Rear panel | |
| 41028043 | Foot | |
| 43023570 | Foot | |
| 41021233 | Filter w/knob without screw | |
| 49007894 | Filt hous w/filter cartridge | |
| 43001052 | Detergent dispenser | |
| 41035313 | Dispenser bottom section | |
| 41022270 | Dispenser top section | |
| 92470061 | Hose clip | |
| 43003751 | Fill hose | |
| 41018989 | Solenoid valve | |
| 92693373 | Drain hose | |
| 92689587 | Drain house elbow | |
| 92895051 | Hose clamp | |
| 43023852 | Hose clamp | |
| 92470012 | Hose clamp D.15 | |
| 92250869 | Fill hose | |
| 41042893 | Analog pressure sensor (APS) | |
| 41044412 | Wiring harness | |
| 91623678 | Mains block | |
| 41019104 | Drain/recycle pump complete | |
| 43014233 | Drain/recycle pump complete | |
| 41041367 | Door safety device | |
| 41037239 | Anti jamming filter radio | |
| 43003846 | Tub complete | |
| 41042927 | Tub gasket clip | |
| 41018408 | Tub gasket clip | |
| 41021881 | Pulley fixing screw | |
| 41015990 | Support spring. | |
| 43005959 | Springs & shock absorb. mounting diagram | |
| 40001133 | Balance weight washer | |
| 92438720 | Self-locking washer | |
| 41021829 | Bolt | |
| 41011359 | Lower balance weight bracket | |
| 43000505 | Upper balance weight | |
| 43000493 | Lower balance weight | |
| 43000586 | Telescopic shock absorber | |
| 41017173 | Shock absorber pin | |
| 41017169 | Antinoise bush | |
| 92673961 | Support | |
| 41021143 | Door gasket | |
| 43021655 | Door gasket | |
| 41021806 | Discharge pipe | |
| 41034869 | Fill pipe | |
| 43004375 | Pressure Switch Hose | |
| 43017576 | Pressure Switch Hose | |
| 41021255 | Hose clip | |
| 92470137 | Hose clip d44 | |
| 92470202 | Hose clip | |
| 41039772 | Heater+NTC | |
| 49015420 | NTC probe | |
| 41029410 | Drum pulley | |
| 41039460 | Drive belt | |
| 43006624 | Bottom panel | |
| 92473636 | Clips | |
| 41041009 | Commutator motor | |
| 41008862 | Power Card Protection | |
| 41043583 | Electronic Control NFC BLE Not Programed | |
| 41044966 | Electronic Control NFC BLE Not Programed | |
| 43024180 | Electronic Control NFC BLE Not Programed | |
| 49035644 | Electronic Control NFC BLE Programmed | |
| 49038459 | Electronic Control NFC BLE Programmed | |
| 49043848 | Electronic Control NFC BLE Programmed | |
| 92419548 | Special bolt | |
| 91200194 | Mains cable | |
| 90467903 | Top sleeve | |
| 41017172 | Shock-absorb.conn.bracket | |
| 41042425 | Filter door | |
| 43000463 | Door handle assembly | |
| 41024476 | Timer protection | |
| 41022267 | Siphon for water softner | |
| 91408004 | Discharge pipe circlip | |
| 92898923 | Lower counterweight supp. | |
| 41021914 | Drum shovel | |
| 41027368 | Upper front crosspiece | |
| 43014103 | Eeprom File NFC | |
| 43018386 | Eeprom File NFC | |
| 43026297 | Eeprom File NFC | |
| 41043569 | Electrical diagram | |
| 41036197 | Disc spring | |
| 49010071 | Transit bolt kit | |
| 41017170 | ||
| 41017173 | ||
| 49007928 | ||
| 41040031 | ||
| 49030345 | ||
| 41022267 | ||
| 41034869 | ||
| 41039789 | ||
| 41016879 | ||
| 41022270 | ||
| 41041527 | ||
| 41019104 |
